  • Turbiti O2 nanobubble generator

The Turbiti O2 is the multipurpose ultrafine bubble generator suitable for agriculture, horticulture and fish cultivation sites. The Turbiti O2 must be combined with an oxygen generator, which creates 90% pure oxygen out of air.

Inside the turbiti O2 is Acniti’s low pressure static mixer swirl flow technology, which creates billions of nano-sized bubbles by beating up the gas water mixture. The Turbiti O2 is flexible to implement, as it can be used with a wide array of pumps.

The turbiti O2 is used for aerating fishponds with nanobubbles. Super saturation of oxygen for water day storage tanks in horticulture. Drinking water solutions for chicken, cows, pigs and horses, giving high DO water with ultrafine bubbles to animals with enhance their food digestion more efficiently and results in healthier animals.

Turbiti wall mounted nanobubble mixer with enhanced aeration technology

  • Clean Tech – Chemical free cleaning solutions
  • easy to implement in existing installations
  • efficient gas dissolution and ultrafine bubble production
  • uses turbiti nanobubble production technology
  • systems in use for poultry and livestock drinking water
  • nanobubble production for irrigation ponds for agriculture
  • combined in wastewater treatment systems
  • special chemical and hydrochloric acid resistant version available

Model

specifications

  • Model nameTurbiti 727 O2 in wall mounted enclosure
    Model numberturbiti_727_wallmount_galvanized-box
    Spec sheetTurbiti 727 O2 in wall mounted enclosure
    LiquidMetricImperial
    Minimum flow / minute 50 Liter13 Gallon
    Maximum flow / minute 100 Liter26 Gallon
    Minimum flow / hour 3.0 M3105.9 CF
    Maximum flow / hour 6.0 M3211.9 CF
    water temperature minimum-20 ℃-4 ℉
    water temperature maximum50 ℃122 ℉
    Strainer availability and sizeNo strainer on the equipment, strainer required when particles larger than 1 or 2 mm.
    Recommended inlet filter(s)Medium pump inlet filter series
    AmbientMetricImperial
    Ambient temperature minimum-20 ℃-4 ℉
    Ambient temperature maximum50 ℃122 ℉
    Relative humidity minimum0 %0 %
    Relative humidity maximum100 %100 %
    GasMetricImperial
    Minimum flow / minute2.5 Liter0.7 Gallon
    Maximum flow / minute5.0 Liter1.3 Gallon
    Minimum flow / hour150 Liter40 Gallon
    Maximum flow / hour300 Liter79 Gallon
    Pressure minimum 50 kPa7 PSI
    Pressure maximum 350 kPa51 PSI
    Gas qualityNo corrosive gasses: suitable for O2, air, CO2, N2
    Gas remarkThe mentioned pressures are recommended pressures for bubble generation. The product itself can withstand pressures up to 500 kPa.
    Electrical
    Unit power consumptionNo pump included with this product. Estimated power consumption 750-1000 watts.
    Wetted partsnylon based resins, PVC, EPDM rubber
    Pump modelRecommended: use of a low head centrifugal pump or pool pump
    Pump pressure settingThis product works well with most low head pumps. Head 10 to 15 meters. (Ask us for more details).
    ControlManual by pressure gauche
    Pump
    @optionEbara-Matrix-5-3
    Connections
    Water inletRigid Rc 1" female coupling with thread
    Water outletrigid Rc 3/4" female coupling with thread
    Gas inlet10 mm standard quick fitting, 3/8 on request
    Dimensions & weightMetricImperial
    Dim. (w) x (d) x (h)644 x 200 x 1040 mm25.4 x 7.9 x 40.9 inch
    weight26.5 Kg58.4 lbs.
    Shipping dim. (w)x(d)x(h)67 x 37 x 107 cm26 x 15 x 42 inch
    Shipping weight35 Kg77 lbs.
    • Easy to integrate with existing pool pumps
  • Model nameTurbiti 737 O2 in wall mounted enclosure
    Model numberturbiti_737_wallmount_galvanized-box
    Spec sheetTurbiti 737 O2 in wall mounted enclosure
    LiquidMetricImperial
    Minimum flow / minute 100 Liter26 Gallon
    Maximum flow / minute 250 Liter66 Gallon
    Minimum flow / hour 6.0 M3211.9 CF
    Maximum flow / hour 15 M3530 CF
    water temperature minimum-20 ℃-4 ℉
    water temperature maximum50 ℃122 ℉
    Strainer availability and sizeNo strainer on the equipment, strainer required when particles larger than 1 or 2 mm.
    Recommended inlet filter(s)Medium pump inlet filter series
    AmbientMetricImperial
    Ambient temperature minimum-20 ℃-4 ℉
    Ambient temperature maximum50 ℃122 ℉
    Relative humidity minimum0 %0 %
    Relative humidity maximum100 %100 %
    GasMetricImperial
    Minimum flow / minute5.0 Liter1.3 Gallon
    Maximum flow / minute8.0 Liter2.1 Gallon
    Minimum flow / hour300 Liter79 Gallon
    Maximum flow / hour480 Liter127 Gallon
    Pressure minimum 50 kPa7 PSI
    Pressure maximum 300 kPa44 PSI
    Gas qualityNo corrosive gasses: suitable for O2, air, CO2, N2
    Gas remarkThe mentioned pressures are recommended pressures for bubble generation. The product itself can withstand pressures up to 500 kPa.
    Electrical
    Unit power consumptionNo pump included with this product. Estimated power consumption 750-1000 watts.
    Wetted partsnylon based resins, PVC, EPDM rubber
    Pump modelRecommended: use of a low head centrifugal pump or pool pump
    Pump pressure settingThis product works well with most low head pumps. Head 10 to 15 meters. (Ask us for more details).
    ControlManual by pressure gauche
    Pump
    @optionGrundfos CM10-1
    @optionEbara pump DWO-400
    Connections
    Water inletRigid Rc 2" female coupling with thread
    Water outletrigid Rc 1" female coupling with thread
    Gas inlet10 mm standard quick fitting, 3/8 on request
    Dimensions & weightMetricImperial
    Dim. (w) x (d) x (h)644 x 200 x 1040 mm25.4 x 7.9 x 40.9 inch
    weight26.5 Kg58.4 lbs.
    Shipping dim. (w)x(d)x(h)67 x 37 x 107 cm26 x 15 x 42 inch
    Shipping weight35 Kg77 lbs.
    • Easy to integrate with existing pool pumps
  • Model nameTurbiti 747 O2 in wall mounted enclosure
    Model numberturbiti_747_wallmount_galvanized-box
    Spec sheetTurbiti 747 O2 in wall mounted enclosure
    LiquidMetricImperial
    Minimum flow / minute 400 Liter106 Gallon
    Maximum flow / minute 500 Liter132 Gallon
    Minimum flow / hour 24 M3848 CF
    Maximum flow / hour 30 M31,059 CF
    water temperature minimum-20 ℃-4 ℉
    water temperature maximum50 ℃122 ℉
    Strainer availability and sizeNo strainer on the equipment, strainer required when particles larger than 1 or 2 mm.
    Recommended inlet filter(s)Medium pump inlet filter series
    AmbientMetricImperial
    Ambient temperature minimum-20 ℃-4 ℉
    Ambient temperature maximum50 ℃122 ℉
    Relative humidity minimum0 %0 %
    Relative humidity maximum100 %100 %
    GasMetricImperial
    Minimum flow / minute5.0 Liter1.3 Gallon
    Maximum flow / minute8.0 Liter2.1 Gallon
    Minimum flow / hour300 Liter79 Gallon
    Maximum flow / hour480 Liter127 Gallon
    Pressure minimum 50 kPa7 PSI
    Pressure maximum 300 kPa44 PSI
    Gas qualityNo corrosive gasses: suitable for O2, air, CO2, N2
    Gas remarkThe mentioned pressures are recommended pressures for bubble generation. The product itself can withstand pressures up to 500 kPa.
    Electrical
    Unit power consumptionNo pump included with this product. Estimated power consumption 1500-2000 watts.
    Wetted partsnylon based resins, PVC, EPDM rubber
    Pump modelRecommended: use of a low head centrifugal pump or pool pump
    Pump pressure settingThis product works well with most low head pumps. Head 10 to 15 meters. (Ask us for more details).
    ControlManual by pressure gauche
    Connections
    Water inletRigid Rc 2" female coupling with thread
    Water outletrigid Rc 1.5" female coupling with thread
    Gas inlet10 mm standard quick fitting, 3/8 on request
    Dimensions & weightMetricImperial
    Dim. (w) x (d) x (h)644 x 200 x 1040 mm25.4 x 7.9 x 40.9 inch
    weight26.5 Kg58.4 lbs.
    Shipping dim. (w)x(d)x(h)67 x 37 x 107 cm26 x 15 x 42 inch
    Shipping weight35 Kg77 lbs.
    • Easy to integrate with existing pool pumps
