  • Industrial ozone generator with oxygen concentrator

Combined O3 and O2 production

The Acniti Oxiti ozone generator is an air-cooled ozone generation unit that generates 5 gram ozone per hour. Oxygen as a raw material is required to produce a high-concentration ozone gas. The Oxiti ozone generator has a built-in oxygen concentrator and therefore guarantees an optimal ozone output. The combined oxygen and ozone generator is compact and can generate ozone immediately. The unit has a switch which can stop ozone production, so only 90% plus oxygen is produced. The ozone generator is build from the best materials such as glass titanium and fluoroplastics, thus the ozone gas doesn't come in contact with any metals, it's free from any metal ions.

Usage and Industries

The oxygen generator with incorporated ozone generator is excellent for research applications where ozone needs to be produced without any contamination. The oxiti ozone can also be used as an ozone supply source for incorporation into water treatment equipment. The principal feature of Oxiti ozone is it can generate high-concentration ozone at a low flow rate. Due to this feature, it is possible to combine it with micro and nanobubble devices and to enable efficient ozone water generation. Acniti can also supply nanobubble generators suitable for ozone gas, check our microStar ozone nanobubble generator or Turbiti ozone and Turbiti land-based nanobubble mixer.

High-quality materials

The Oxiti ozone generator has a quartz glass tube ozone cell which is sturdy, hard and compact, complemented with titanium wires to produce ozone. The quartz glass generator has a service life of 16,000 hours, compare that with a ceramic plate ozone generator which only lasts 3,000 to 5,000 hours. Apart from the glass titanium dielectric tube the tubing and fittings are made from fluoroplastics, the tubing is made from FEP (fluorinated ethylene propylene) and fittings from PTFE (Polytetrafluoroethylene).

Oxiti Ozone: Ozone generator with oxygen sieves

  • Ozone gas contact part is metal free
  • ozone concentration easily adjusted with the volume control knob on the front panel
  • Ozone generation method: Dielectric discharge method

Model

specifications

  • Model nameindustrial ozone with oxygencentrator 8 LPM 115V
    Model numberoxiti-08-O3-5G-115
    Spec sheetindustrial ozone with oxygencentrator 8 LPM 115V
    AmbientMetricImperial
    Ambient temperature minimum10 ℃50 ℉
    Ambient temperature maximum40 ℃104 ℉
    Relative humidity minimum15 %15 %
    Relative humidity maximum90 %90 %
    Electrical
    Unit phase Ø voltage1 Ø 115 VAC 60 Hz
    Unit power consumption500 watts
    Connections
    Gas inlet10 mm push to connect fitting or 3/8" on request
    Dimensions & weightMetricImperial
    Dim. (w) x (d) x (h)460 x 444 x 695 mm18.1 x 17.5 x 27.4 inch
    weight33.5 Kg73.9 lbs.
    Shipping dim. (w)x(d)x(h)62 x 54.5 x 760 cm24 x 21 x 299 inch
    Shipping weight35 Kg77 lbs.
    • Altitude 21 degrees up to 1500 meter (5000 ft) without degradation, contact us for more information regarding 1,500 m to 4,000 m (5,000 - 13,000 ft)
    • Storage temperature from - 20 °C to 60 °C (0°F to 140 °F)
    • unprotected or inadequately ventilated environment or improper control power may cause damage to the oxygen concentrator and is not covered under warranty.
  • Model nameIndustrial ozone with oxygencentrator 8 LPM 230V
    Model numberoxiti-08-O3-5G-230
    Spec sheetIndustrial ozone with oxygencentrator 8 LPM 230V
    AmbientMetricImperial
    Ambient temperature minimum10 ℃50 ℉
    Ambient temperature maximum40 ℃104 ℉
    Relative humidity minimum15 %15 %
    Relative humidity maximum90 %90 %
    GasMetricImperial
    Minimum flow / minute2.0 Liter0.5 Gallon
    Maximum flow / minute8.0 Liter2.1 Gallon
    Minimum flow / minute2.0 Liter0.5 Gallon
    Maximum flow / minute8.0 Liter2.1 Gallon
    Minimum flow / hour120 Liter32 Gallon
    Maximum flow / hour480 Liter127 Gallon
    Minimum flow / hour120 Liter32 Gallon
    Maximum flow / hour480 Liter127 Gallon
    Electrical
    Unit phase Ø voltage1 Ø 230 VAC 50/60 Hz
    Unit power consumption500 watts
    Wetted partsQuartz glass, PFA, PTFE
    Connections
    Gas inlet10 mm push to connect fitting or 3/8" on request
    Dimensions & weightMetricImperial
    Dim. (w) x (d) x (h)460 x 444 x 695 mm18.1 x 17.5 x 27.4 inch
    weight33.5 Kg73.9 lbs.
    Shipping dim. (w)x(d)x(h)62 x 54.5 x 76 cm24 x 21 x 30 inch
    Shipping weight35 Kg77 lbs.
    • Aircooled
    • Energy consumption 80 watt for ozone generator only
