  • Turbiti O2 nanobubble generator

The Turbiti O2 is the multipurpose ultrafine bubble generator suitable for agriculture, horticulture and fish cultivation sites. The Turbiti O2 must be combined with an oxygen generator, which creates 90% pure oxygen out of air.

Inside the turbiti O2 is Acniti’s low pressure static mixer swirl flow technology, which creates billions of nano-sized bubbles by beating up the gas water mixture. The Turbiti O2 is flexible to implement, as it can be used with a wide array of pumps.

The turbiti O2 is used for aerating fishponds with nanobubbles. Super saturation of oxygen for water day storage tanks in horticulture. Drinking water solutions for chicken, cows, pigs and horses, giving high DO water with ultrafine bubbles to animals with enhance their food digestion more efficiently and results in healthier animals.

Turbiti O2 land-based nanobubble mixer

  • Clean Tech – Chemical free cleaning solutions
  • easy to implement in existing installations
  • efficient gas dissolution and ultrafine bubble production
  • uses turbiti nanobubble production technology
  • systems in use for poultry and livestock drinking water
  • nanobubble production for irrigation ponds for agriculture
  • combined in wastewater treatment systems
  • special chemical and hydrochloric acid resistant version available

Model

specifications

Model nameTurbiti 737 O2 land-based nano bubble
Model numberturbiti_mb_737-O2_s
LiquidMetricImperial
Minimum flow / minute 100 Liter26 Gallon
Maximum flow / minute 250 Liter66 Gallon
Minimum flow / hour 6.0 M3211.9 CF
Maximum flow / hour 15 M3530 CF
water temperature minimum-20 ℃-4 ℉
water temperature maximum50 ℃122 ℉
Strainer availability and sizeNo strainer on the equipment, strainer required when particles larger than 1 or 2 mm.
Recommended inlet filter(s)RF200
AmbientMetricImperial
Ambient temperature minimum-20 ℃-4 ℉
Ambient temperature maximum50 ℃122 ℉
Relative humidity minimum0 %0 %
Relative humidity maximum100 %100 %
GasMetricImperial
Flow / minute8.0 Liter2.1 Gallon
Flow / hour480 Liter127 Gallon
Pressure minimum 40 kPa6 PSI
Pressure maximum 200 kPa29 PSI
Gas qualityNo corrosive gasses: suitable for O2, air, CO2, N2
Gas remarkThe mentioned pressures are recommended pressures for bubble generation. The product itself can withstand pressures up to 500 kPa.
Electrical
Unit power consumptionNo pump included with this product. Estimated power consumption 750-1000 watts.
Wetted partsnylon based resins, PVC, EPDM rubber
Pump modelRecommended: use of a low head centrifugal pump or pool pump
Pump pressure settingThis product works well with most low head pumps. Head 10 to 15 meters. (Ask us for more details).
ControlManual by pressure gauche
Connections
Water inletRigid RC 2" female coupling with thread
Water outletrigid Rc 1" female coupling with thread
Gas inlet10 mm standard quick fitting, 3/8 on request
Dimensions & weightMetricImperial
Dim. (w) x (d) x (h)644 x 200 x 1040 mm25.4 x 7.9 x 40.9 inch
weight26.5 Kg58.4 lbs.
Shipping dim. (w)x(d)x(h)67 x 37 x 107 cm26 x 15 x 42 inch
Shipping weight35 Kg77 lbs.
  • Easy to integrate with existing pool pumps
